Model: MT-062A Yellow powder coating
Epoxy-polyester thermosetting electrostatic spray powder coating is a hybrid material combining epoxy resin and polyester resin, offering superior flowability, decorative properties, mechanical strength, and corrosion resistance. This coating is widely used for indoor metal surface protection in automotive, home appliance, metal furniture, instrumentation, fitness equipment, and radiator industries. Its dual-resin formulation ensures excellent adhesion, impact resistance, and chemical stability, making it a preferred choice for high-performance industrial applications.
| Parameter | Specification |
|---|---|
| Density | 1.1–1.8 g/cm³ (varies by type/color) |
| Horizontal Flowability | 18–35 mm |
| Particle Size Distribution | 100% < 125 μm; >85% within 60–90 μm |
| Curing Conditions | Standard: 180°C (workpiece temp.) for 15 min |
| Low-Temperature: 160°C for 15 min | |
| Coverage Rate | 9–12 m²/kg at 80 μm film thickness (100% utilization) |
| Gloss Levels | High-gloss (>80%), Semi-gloss (40–60%), Matte (15–50%) |
| Mechanical Properties | Pencil Hardness: ≥2H (GB/T 6739-86) |
| Adhesion: Grade 0 (GB/T 9286-88) | |
| Bending Test: Pass at 3 mm taper (GB/T 11185-88) | |
| Impact Resistance: ≥50 kg·cm (GB/T 1732-93) | |
| Corrosion Resistance | Salt Spray Test: 500 h (Grade 1. GB/T 1771-91) |
| Humidity Resistance: 500 h (Grade 1. BS.3900 Part F2) | |
| Cupping Test | 6 mm deformation resistance |
This coating is primarily used for indoor metal surface protection, including:
Its adaptability to various curing conditions (standard/low-temperature) enables compatibility with diverse production schedules.
Storage: Maintain below 25°C in ventilated, dry, and clean environments. Avoid direct sunlight, fire sources, and heating equipment. Stable shelf life up to 12 months when stored under recommended conditions.
Transportation: Use air-conditioned vehicles or transport during cooler periods to prevent heat-induced degradation. Avoid exposure to moisture or humidity, which may compromise powder flowability and electrostatic properties.
Powder coatings can be categorized by resin system (epoxy, polyester, hybrid, polyurethane), appearance (smooth, texture, hammer, metallic, pearlescent), or performance level (anti-corrosion, heat-resistant, UV-resistant, architectural grade, automotive grade).
Powder coatings offer thousands of colors in gloss, matte, satin, metallic, candy, texture, wrinkle, hammer tone, wood grain, fluorescent, and other custom effects. Special powders can create soft-touch, anti-scratch, anti-fingerprint, or anti-graffiti surfaces.
The process generally includes surface pretreatment (degreasing, phosphating, chromating, sandblasting), drying, electrostatic spraying, curing in an oven, and cooling. A well-controlled pretreatment and curing process ensures strong adhesion and long service life.
Powder coatings are environmentally friendly, solvent-free, and produce minimal waste. They offer excellent corrosion resistance, weather durability, mechanical strength, and uniform film appearance. The coating is tough, impact-resistant, scratch-resistant, and has a long lifespan.
Powder coatings are widely used in appliances, aluminum profiles, architectural components, automotive parts, bicycles, furniture, outdoor equipment, machinery, electrical cabinets, pipeline systems, and general industrial and consumer goods.
Powder coating is a dry finishing technology where finely ground powder is electrostatically sprayed onto a metal or non-metal surface and then cured at high temperature. After curing, the powder melts into a continuous, durable, and decorative coating layer.
Powder coating protects the substrate from corrosion, weathering, chemical attack, and mechanical wear. It also provides decorative appearance with rich colors, gloss levels, textures, and special effects.
In many industrial applications, powder coating outperforms liquid paint. It forms a thicker and tougher coating, resists corrosion and chemicals better, and does not contain VOCs. It also provides excellent consistency and cost-effective mass production.
It is called powder coating because the coating material is a solid powder instead of a liquid paint. The coating is formed by melting and curing powder particles under heat.
Powder coatings include several families depending on resin chemistry:
• Epoxy powders
• Polyester powders
• Epoxy-polyester hybrid powders
• Polyurethane powders
• Acrylic powders
• Fluorocarbon (PVDF) powders
Each type has its own performance features such as corrosion resistance, UV resistance, chemical resistance, outdoor durability, or decorative properties.
Powder coatings are based on thermoset or thermoplastic resins combined with pigments, curing agents, fillers, additives, and in some cases metallic or effect particles. Common substrates include steel, aluminum, galvanized metal, MDF, and certain heat-resistant plastics.
The lifespan depends on powder type, film thickness, application method, pretreatment, and service environment. Indoor coatings can last more than 10–20 years. High-grade outdoor polyester or fluorocarbon powders can last 15–25 years or longer under UV exposure.
